Features
- No crusher backing required –
behind the liners which allows the crusher to be operational immediately after a liner change - Direct drive –
through a wet clutch with eight SPC drive belts to ensure maximum fuel efficiency and power delivery - Variable crusher speed –
through the engine rpm to manipulate the gradation of the end product - Maximum feed size up to 185 mm –
and capable of up to 220 tph on the larger bush setting - Remote camera –
which makes the crushing chamber visible from ground level
- No crusher backing required –
-
Product Data
Equipment Sandvik CH430 Cone Max. feed size 214 mm (8 in.) Capacity 220 mtph (242 stph) Engine C9.3B 280 / C9.3 261 Transport length 15.9 m (52.0 ft) Transport width 2.9 m (9.6 ft) Transport height 3.4 m (11.2 ft) Weight 38,031 kg (86,048 lb) -
Additional Product Information
Sandvik CH430 cone crusher is at the heart of this machine. This advanced piece of crushing technology comes equipped with a hydroset system, which puts the user first by providing both safety and setting adjustment functions. In addition, the automatic setting regulation system will not only optimizes production for you but will also keep track of liner wear, minimizing interruptions and maximizing uptime.
The cone comes with a choice of six different crushing chambers and a number of different bush settings, making it the ideal choice for a huge variety of crushing jobs. This machine is powered by a 261kW (350hp) engine and a fuel efficient direct drive system to ensure maximum production capacity and maximum power transfer.
Also within this range is Sandvik QH441 Opens in new windowand QS332 cone crusher.
-
Additional Advantages
- Optional double or single deck hanging screen for 1, 2 or 3 way split.
- My Fleet remote monitoring system – with 7 year data subscription to help optimize your machine operation
- Security+ extended warranty & service package for higher uptime and peace of mind
