UJ443E Jaw crusher

Sandvik Mobile Crushers and Screens continues to drive the sustainability shift in the crushing and screening industry with our new fully electric, UJ443E heavy tracked jaw crusher.

Equipment: Sandvik CJ412 jaw crusher

Feed opening: 1,200 x 830 mm (47 x 33 in.)

Max. feed size: 750 mm (30 in.)

Capacity: Up to 700 mtph (770stph)

Enquire about this equipment
Contact us
  • Features
    • Heavy duty unit –
      designed for hard and abrasive rock
    • Capable of operating in the toughest conditions
    • All onboard components are electrically driven –
      including the tracks
    • Latest CJ412 jaw crusher –
      removable for transport
    • Class leading 1400mm (55 in.) wide main conveyor –
      now angle adjustable and extended with remote hydraulic lock out
    • Redesigned feed station –
      with patent pending hydraulic lift function
  • Product Data
    EquipmentSandvik CJ412 Jaw Crusher
    Feed opening1200 x 830 mm (47 x 33 in.)
    Max. feed size750 mm (30 in.)
    CapacityUp to 700 mtph (770 stph)
    PowerDiesel generator 400 V / 230 V 24 V 50 Hz
    Transport length excl NF conveyor16.8 m (55.6 ft)
    Transport length incl NF conveyor17.2 m (56.6 ft)
    Transport width3.0 m (9.1 ft)
    Transport height3.9 m (12.1 ft)
    Weight VGF and US (excl NF conveyor)69,500 kg (153,221 lb)
    Weight VGF and US (incl NF conveyor)71,000 kg (156,528 lb)

    Can be split in two parts for road transport: Plant less crusher (38,645 kg / 85,197 lbs excluding NF Conveyor) or (40,145 kg / 88,504 lbs including NF Conveyor) + (Base crusher 30,855 kg / 68,023 lbs)

  • Additional Product Information

    Using our decades of experience and knowledge in building robust, sustainable, powerful, and fully electric crushing and screening units, the UJ443E is the newest innovation in Sandvik’s sustainable heavy range of units.

    The UJ443E heavy jaw crusher has been designed with increased focus on productivity, sustainability, and durability.

    The UJ443E allows you to choose your preferred energy source, either connected to an external electricity supply or via the onboard genset using HVO or diesel.

    Operating whilst connected can bring several advantages including, significantly lowering running costs, extending drivetrain service intervals, reducing time spent refuelling, reducing onsite emissions and lower noise levels.

    With a host of new innovative features on the UJ443E, we break boundaries, so you can crush rock.

  • Additional Advantages
    • Feed hopper with patent pending folding and locking mechanism
    • Two rubber lined feeder options available, a vibrating grizzly for clean rock or a vibrating grizzly with under-screen for rock containing fines
    • A larger bypass chute and optional natural fines conveyor
    • Optik™ automation system
    • Crusher unblock software
    • Onboard low emission diesel electric genset
