QI341 HSI impact crusher


Sandvik QI341 mobile impact crusher is the most versatile and cost effective mid-sized unit on the market. Fitted with the CI611 Prisec™ impactor, this unit can operate in both primary and secondary applications.

Equipment: Sandvik Prisec™ HSI

Feed opening: 992 x 670 mm (39 x 26 in.) mm

Max. feed size: Up to 600 mm (24 in.)

Capacity: Up to 300 mtph (330 stph)

Enquire about this equipment
Contact us
  • Features
    • User friendly PLC control system –
      and color screen for ease of operation
    • Raise/lower capability –
      on the main conveyor, magnet and ceramic blow bars as standard
    • Adjustable tip speed –
      with automatic backflush feature
    • Reversible hydraulically-driven cooling fan –
      for simple and efficient operation
    • Wear-resistant feeder liner plates –
      are standard, reducing wear cost
  • Product Data
    EquipmentSandvik Prisec™ HSI
    Feed opening992 x 670 mm (39 x 26 in.)
    Max. feed sizeUp to 600 mm (24 in.)
    EngineC9 / C9.3 Acert 261 kW (350 hp)*
    CapacityUp to 300 mtph (330 stph)
    Transport length14.1 m (46.2 ft)
    Transport width2.5 m (8.2 ft)
    Transport height3.4 m (11.2 ft)
    Weight40,276 kg (88,793 lb)

    * Please refer to technical specification sheet for alternative engine options.
    Please note all weights and dimensions are for standard units only.

  • Additional Product Information

    This fully mobile, compact impact crusher is designed to meet the tightest end-product specifications while providing the operator an unparalleled level of flexibility, productivity and control. The compact dimensions of Sandvik QI341 mobile impactor make it ideal for sites where space is limited, but where superb product shape and high levels of production are required.

    The unique crescent profile design of the hammers ensures maximum reduction of material, even as the hammers wear. The 992 x 670 mm (39 x 26½ in.) feed opening can be raised by radio control, and the rotor speed is adjustable to control fines production. Available in open or closed circuit versions, Sandvik QI341 mobile impact crusher is the ultimate contractor machine.

    Other models within this range include Sandvik QI442 impact crusher and Sandvik QI353 impact crusher.

  • Additional Advantages
    • Compact layout and excellent stability
    • Security+ extended warranty & service package for higher uptime and peace of mind.
