Applications
- Stockpiling
- Transport
- Loading
- Sorting and others
-
Performance highlights
- Battery driven plug-in version available
- Available in Diesel/Hydraulic drive & Diesel/Electric drive
- 75% cost saving capacity compared to a loading shovel
- Very good stockpiling capabilities
- Main conveyor 1.000 mm (39”) wide, 23.000 mm (75’) long
- Feed capacity up to 500 tonnes an hour
- Stockpile capacity from 2.500 tonnes to 15.000 tonnes
- Discharge height from 6 meter (20’) to 9,4 meter (31’)
-
Specifications
Transport dimensions Weight 12 t (13 sT) Length 12.700 mm (39’4”) Height 2.760 mm (9’) Width 2.290 mm (7’6”)
