Performance highlights
- Automatic swiveling via ultrasonic sensor to create radial stockpile
- 75% cost saving capacity compared to a loading shovel
- Very good stockpiling capabilities
- Main conveyor 650 mm (2’2″) wide, 10.500 mm (34’5″) long
- Feed capacity up to 280 tonnes an hour
- Available in electric plug-in version
- Stockpile capacity from 450 to 2.900 ton
- Discharge height from 5,3 meter (17’5″) to 6,35 meter (20’10”)
-
Applications
- Stockpiling
- Transport
- Loading
-
Specifications
Transport dimensions Working dimensions Weight 5,45 t (6 sT) 5,45 t (6 sT) Length 12.000 mm (39’4″) 12.800 mm (41’11”) Height 2.350 mm (7’9″) 6.350 mm (20’10”) Width 1.280 mm (4’2″) 1.900 mm (6’3″)
