Specifications are subject to change without notice (Wednesday, August 23, 2023)
-
APPLICATIONS
- Trench compaction
- Slope compaction
- Pile Driving
- Waste Material Compaction
-
Specification
Minimum working weight, flange mounted *1 750 lb Height 546 mm 21.5 in Carrier weight, range *2 3.6 – 9 t 8000 – 20000 lb Impulse force 6400 lb Operating frequency 2000 rpm Hydraulic flow options 6/9/14/18 gal/min Compaction plate dimensions 18 x 35 in Mounting bracket type XR/BR *1 Includes average mounting bracket and standard wear parts
*2 Check carrier allowed attachment weight from carrier manufacturer. Check application requirements.
