B7e Jaw


Coming soon

Enquire about this equipment
Contact us
  • Applications
    • Quarrying and mining
    • Granite, Basalt, and medium and hard stone
    • Primary crushing
    • Concrete and landfill recycling
    • Construction waste
    • Demolition
    • Gravel
    • Coal, slag, and others
  • Performance Highlights
    • Feed size up to 700 mm (28”)
    • Vibrating feeder with 2step grizzly 2.200 mm x 1.080 mm (7’3″ x 3’7″)
    • Feed opening 1.200 x 830 mm (47” x 32,7”)
    • C.S.S. min. – max. 75 – 250 mm (3″ – 10”)
    • Capacity up to 600 tonnes/hour
    • Full hybrid electric driven, energy-saving version available
    • Removable feed hopper and feeder with scalper for transport
    • Intake hopper suitable for wheel loader and excavator, 6 m³ (7,8 yard³)
    • Hydraulic gap adjustment to safely prevent clogging
    • Smart sequential auto start/stop from remote
    • Ability to track while producing
    • 2-speed track drive
    • Extensive option list to configure to your application
    • Removable engine /generator compartment
  • Specifications
    Transport DimensionsWorking Dimensions
    Weight69 t (76 sT)
    Length15.131 mm (49’8”)16.840 mm (55’3”)
    Height3.675 mm (12’1″)4.325 mm (14’2”)
    Width3.000 mm (9’10”)5.800 mm (19′)
